| Product model number | Mled-PH16-1 |
| 1.Pixel |
| Pixel L ED | 546 |
| Pixel Configuration | 2 R, 1G , 1B |
| Wave length ( nm ) | R: 800-1000 , G:2040-2450, B: 360-430 |
| Pixels Pitch ( mm ) | 16 |
| 2 . Module |
| Module Size ( mm ) | 256 * 128 * 20 |
| Module Pixels (dot) | 16 * 8 |
| 3.Unit box |
| Module quantities in a unit box | 4 (L) * 6 ( H ) |
| Unit box size ( mm ) | 1024 (L) * 768 (H) * 180 |
| Unit box Pixels ( dot ) | 64 * 48 |
| Unit box material | Aluminum or Iron |
| Unit box weight (kg)
| Aluminum : 42 or Iron : 55
|
| 4.Packaging |
| Packing Way | Two unit boxes packed into one |
| Packing box material | Wooden case or Flight box |
| Packing box size (mm) | 1150 * 950 * 480 |
| 5.electricity parameter |
| Pixel density (dots/ m 2 ) | 3906 |
| White Balance Brightness ( cd/m 2 ) | ≥ 8500 |
| Color temperature ( K ) | 5000-9500 (choice by user) |
| Brightness Adjusted | 100 grade by software or by Auto-optic induced. |
| View Angel | Horizontal 110 ° ; Vertical 70 ° |
| Best viewing distance ( m ) | 16-150 |
| Communication distance ( m ) | Internet Wire : 120 Fiber Cable : 1000 |
| Screen work Method | Static |
| LED driving method | Constant driving current |
| Gray Grades | 16384 levels for each color |
| Display Color | 4 , 398 , 046 , 511 , 104 |
| Refresh Frequency ( Hz ) | ≥ 800 |
| Picture display method | Dots to dots display synchronized with CRT |
| Signal interface | DVI |
| Input signal | Video : PAL/NTSC optioned . VGA, Svideo, DVD, TV |
| Display format | 800 * 600 , 1024 * 768 , 1280 * 1024 |
| Software | Support windows series system |
| Protection grades | IP 65 |
| Working temperature (ºC ) | -10 +50 |
| Humidity ( RH ) | Up to 95 |
| Stored temperature ( ºC) | -30 +70 |
| Screen Lifetime(hours) | ≥100, 000 |
| Out of controlled dots | ≤3/10, 000 (Out of controlled dots means the pixels of which the brightness, and the wave length are both >10% depart to the normal one) |
| Whole display flatnes | Less than 1mm Juncture |
| Maintance way | Back-maintained or front-maintained,
modules displaced |
| Switch power supply | Switch power supply (include CE/GS or UL/CSA certificate) 110V/60HZ , 220V/50HZ |
| Power Consumption ( w /m 2 ) | Max : 1000 , Average: ≥ 450 |
